MGI jetvarnish 3D Evo professionell skrivare

MGI JETVARNISH 3D EVOLUTION

Digital partiell UV-lack/varmfoliering för 2D-/3D-effekter
Gör vanliga printjobb till enastående och tilltalande tryck
Ger lysande folieeffekter på digitaltryck och offset
Perfekt registrering med den revolutionerande AIS SmartScanner
För att sticka ut och addera mervärde

Kontakta oss

Egenskaper

Stick ut från mängden

Om du letar efter ett sätt att sticka ut från mängden och uppgradera dina tjänster, välj MGI JETvarnish 3D Evolution som den perfekta lösningen för leverantörer av digitaltryck och offsettryck. Förvandla vanliga utskriftsjobb till enastående och tilltalande tryck med hjälp av spotlackering av digitaltryck och offsettryck, eller med taktila 3D-effekter med den digitala MGI JETvarnish 3D Evolution för spot-UV-bestrykning. Med den inbyggda modulen för in-line varmfoliering får du en ännu glamorösare finish.

Specifikationer & downloads

Specifikationer

Product Specifications - iFOIL-L
Printing technology	Exclusive MGI inkjet engine technology Drop-on-Demand (DoD) inkjet application Piezoelectric print heads in single pass printing
Coating thicknesses	Depending on the print file and substrate used, the coating thickness can vary from a traditional flat spot UV coating of 3** μm up to 232 μm for 3D raised texture effects and a tactile finish.
Production speed	Up to 3,123 ISO B2 sheets per hour in all versions The version Evo 75 can reach up to 4,200* ISO B2 sheets per hour (in landscape) and up to 2,291 ISO B1 sheets per hour
Registration	SmartScanner coupled with Artificial Intelligence (AIS) for a real-time fully automated sheet-to-sheet registration process No crop marks required
Formats	Min: 42 x 29.7 cm Max: 52 x 120 mm 75 x 120 mm
Printable areas	Max: 51 cm / 74 cm
Substrate thickness	Min: 135 gsm and not less than 150 μm before printing & lamination Max: 800 gsm and not more than 800 μm before printing & lamination ***
Substrates	Enhancement on most** matte or glossy laminated surfaces, with or without aqueous coating, layered paper, plastic, PVC and other coated materials. The used substrate needs to be either coated or laminated. Otherwise the media will absorb the varnish and the desired effect might be lost
Varnish on toner	Spot 3D coat directly onto most** digital prints
UV coatings and capacity	1 coating tank for both 2D & 3D applications One high capacity tank of 18 litres “On-the-fly” tank changeover possible during production without any interruption and no waste
Automatic feeder	High capacity feeder for paper stacks of up to 60 cm height for 75 x 120 cm sheets *** Approximately 4,000 sheets at 135 gsm
Pallet stacker	Supports sheets of up to 75 x 120 cm size on pallet packaging
Paper path	100% flat paper path Vacuum feed system Air feed system Automatic double sheet detection
Front end system	Intuitive touchscreen software management suite controlled by a 27’’ monitor Job cost calculator, image editor, queue manager and reprint, camera and print head settings and reprint, dedicated controller for equipment settings and technical data Ethernet connection 10/100/1000 BT in RJ 45
In-line UV dryer	“On-the-fly” drying & curing via integrated UV lamps
Maintenance & remote technical support	Automated inkjet head cleaning and wiping Daily maintenance completed in less than 10 min Mainly automated procedures From cold start to production in less than 15 min Remote troubleshooting & support via included web video camera (high-speed internet connection required)
Operator panel	Integrated user-friendly LCD touchscreen
Production speed	Up to 2,300 B2 landscape sheets per hour
Formats	Up to 75 x 120 cm
Hot foil stamping area	Max: 74 x 119 cm
Substrate thickness	Min: 150 μm Max: 600 μm (standard), 800 μm (optional)
Foil rolls	Max. roll diameter and length: approx. 30 cm and from 400 to 2,000 meters of film Up to 5 simultaneous film rolls on the same axis (with a minimum of 10 cm per roll) 2 cores available Change for: 1 inch as standard and 3 inches as option
Dry air	Requires air without oil at 6 bar (87 psi) & 24 m3/h (14 cfm)
Product Specifications - MGI JETVARNISH 3D EVOLUTION + IFOIL-L
Dimensions (L x W x H)	Up to 12.72 x 1.86 x 1.84 meter (Evo 75 full options)
Weight	Approx. 4,524 kg
Electrical requirements	40 kW (63 A) at 400 Volts - 50/60 Hz + 20 kW (32 A) at 400 Volts - 50/60 Hz
Temperature	18 to 30°C
Relative humidity	between 30 and 50% (no condensation)
Options
Corona1/2 substrates treatment module	In-line system to optimise varnish adhesion on complex printed substrates
Variable Data Printing (VDP)	– Full variable data (text, graphic, image) for both 2D/3D spot coating and hot foiling areas – Integrated barcode (1D/2D) reader system & controller – Raster Image Processor (RIP) as an option

* With the 75cm/Evo kit.
** Confirm substrate/toner/metallic film compatibility with MGI.
*** With optional pallet feeder and stacker. Corona Surface Treatment Option might affect the max. thickness of media, which can be used on the MGI JETvarnish 3D EVO. Please get in touch with Konica Minolta/ MGI for any further details and an exact Validation

The support and availability of the listed specifications and functionalities varies depending on applications as well as system configurations.
The stated life expectancy of each consumable is based on specific operating conditions such as page coverage for a particular page size. The actual life of each consumable will vary depending on use and other printing variables including page coverage, page size, media type, continuous or intermittent printing, ambient temperature and humidity.
Some of the product illustrations contain optional accessories.
Specifications and accessories are based on the information available at the time of printing and are subject to change without notice.
Konica Minolta does not warrant that any prices or specifications mentioned will be error-free.
All brand and product names may be registered trademarks or trademarks of their respective holders and are hereby acknowledged.

The support and availability of the listed specifications and functionalities varies depending on operating systems, applications, network protocols as well as network and system configurations.
Some of the product illustrations contain optional accessories.
Specifications and accessories are based on the information available at the time of printing and are subject to change without notice.
Konica Minolta does not warrant that all specifications mentioned will be error-free.
Microsoft, Windows and the Windows logo are trademarks, or registered trademarks, of Microsoft Corporation in the United States and/or other countries.
All other brand and product names may be registered trademarks or trademarks of their respective holders and are hereby acknowledged.

Hämta produktbroschyren för att få all information.

MGI JETvarnish 3D Evolution broschyr
